HTD profile

Toothed pulleys profile HTD are precision injection molded and glass reinforced to provide efficient power transmission without slippage or backlash. The combination of metal and nylon in this way allows for a high strength-to-weight ratio and low inertia. HTD pulleys are commonly used in machine tools, small machines, compressors, packaging, printing machines, food, paper and chemical industries and many other machines.

Filter by :

Reset all filters

Validate filters automatically

Bore

With removable hub

181

Pre-bored

335

Section

14M

192

188

Material

Steel

172

Aluminium

Fonte

250

Stainless steel

Vue en tableau

Grid view

Products only in stock

Reference		Stock France	Stock Europe	Net price	Bore	Hub type	Section	Metric Pitch (mm)	Material	Number of teeth	Belt width (mm)	De (mm)	Def (mm)	Mass (Kg)
14MZ028-040M	Added	19 PCE	107 PCE	30,61 €	A moyeu amovible	2012	14M	14	Steel	28	40	122	128	2Kg
14MZ028-040 Tariff - Remanufacturing	Added	3 PCE	382 PCE	38,20 €	Pré alésée		14M	14	Steel	28	40	122	128	4.73Kg
14MZ028-055M	Added	10 PCE	100 PCE	37,05 €	A moyeu amovible	2012	14M	14	Steel	28	55	122	128	2.2Kg
14MZ028-055 Tariff - Remanufacturing	Added	17 PCE	170 PCE	45,85 €	Pré alésée		14M	14	Steel	28	55	122	128	5.6Kg
14MZ028-085M	Added	32 PCE	42 PCE	49,29 €	A moyeu amovible	2517	14M	14	Fonte	28	85	122	128	2.75Kg
14MZ028-085 Tariff - Remanufacturing	Added	32 PCE	45 PCE	60,94 €	Pré alésée		14M	14	Steel	28	85	122	128	7.7Kg
14MZ028-115M	Added	18 PCE	23 PCE	61,12 €	A moyeu amovible	2517	14M	14	Fonte	28	115	122	128	3.75Kg
14MZ028-115 Tariff - Remanufacturing	Added	17 PCE	11 PCE	74,97 €	Pré alésée		14M	14	Fonte	28	115	122	128	9.2Kg
14MZ028-170 Tariff - Remanufacturing	Added	0	10 PCE	100,27 €	Pré alésée		14M	14	Fonte	28	170	122	128	13.8Kg
14MZ029-040M	Added	14 PCE	0	32,56 €	A moyeu amovible	2012	14M	14	Steel	29	40	127	138	2.6Kg
14MZ029-040 Tariff - Remanufacturing	Added	1 PCE	23 PCE	41,93 €	Pré alésée		14M	14	Fonte	29	40	127	138	5.09Kg
14MZ029-055M	Added	16 PCE	7 PCE	41,36 €	A moyeu amovible	2012	14M	14	Steel	29	55	127	138	N.C
14MZ029-055 Tariff - Remanufacturing	Added	0	15 PCE	50,28 €	Pré alésée		14M	14	Fonte	29	55	127	138	6.1Kg
14MZ029-085M	Added	31 PCE	63 PCE	55,06 €	A moyeu amovible	2517	14M	14	Fonte	29	85	127	138	3.25Kg
14MZ029-115M	Added	2 PCE	0	65,47 €	A moyeu amovible	2517	14M	14	Fonte	29	115	127	138	N.C
14MZ030-040M	Added	21 PCE	1720 PCE	37,84 €	A moyeu amovible	2012	14M	14	Steel	30	40	131	138	2.65Kg
14MZ030-040 Tariff - Remanufacturing	Added	27 PCE	169 PCE	46,54 €	Pré alésée		14M	14	Fonte	30	40	131	138	5.45Kg
14MZ030-055 Tariff - Remanufacturing	Added	51 PCE	13 PCE	55,83 €	Pré alésée		14M	14	Fonte	30	55	131	138	6.6Kg
14MZ030-055AC Tariff - Remanufacturing	Added	0	0	66,66 €	Pré alésée		14M	14	Steel	30	55		138	6.6Kg
14MZ030-055M	Added	25 PCE	322 PCE	45,53 €	A moyeu amovible	2517	14M	14	Steel	30	55	131	138	2.7Kg
14MZ030-085 Tariff - Remanufacturing	Added	51 PCE	19 PCE	74,22 €	Pré alésée		14M	14	Fonte	30	85	131	138	9.1Kg
14MZ030-085M	Added	26 PCE	56 PCE	60,81 €	A moyeu amovible	2517	14M	14	Fonte	30	85	131	138	3.75Kg
14MZ030-115 Tariff - Remanufacturing	Added	7 PCE	24 PCE	91,32 €	Pré alésée		14M	14	Fonte	30	115	131	138	11.2Kg
14MZ030-115M	Added	5 PCE	2 PCE	76,45 €	A moyeu amovible	2517	14M	14	Fonte	30	115	131	138	5Kg
14MZ030-170 Tariff - Remanufacturing	Added	0	4 PCE	122,25 €	Pré alésée		14M	14	Fonte	30	170	131	138	15.6Kg
14MZ032-040 Tariff - Remanufacturing	Added	129 PCE	24 PCE	52,65 €	Pré alésée		14M	14	Fonte	32	40	140	154	6.17Kg
14MZ032-040M	Added	48 PCE	363 PCE	42,80 €	A moyeu amovible	2012	14M	14	Steel	32	40	140	154	3.4Kg
14MZ032-055 Tariff - Remanufacturing	Added	69 PCE	252 PCE	63,28 €	Pré alésée		14M	14	Steel	32	55	140	154	7.6Kg
14MZ032-055M	Added	1 PCE	225 PCE	51,86 €	A moyeu amovible	2517	14M	14	Steel	32	55	140	154	3.65Kg
14MZ032-085 Tariff - Remanufacturing	Added	23 PCE	12 PCE	84,30 €	Pré alésée		14M	14	Fonte	32	85	140	154	10.5Kg

0-30 sur 516
