GT Profile

The deep tooth design of the PowerGrip systems increases the contact area, which improves ratchet resistance. The modified curvilinear teeth enter and exit the pulley grooves cleanly, reducing vibration. The GT Synchronous Pulley-Belt System offers the following benefits: - Longer belt life - Precision registration - Increased load capacity - Quieter operation - Precise positioning

Filter by :

Reset all filters

Validate filters automatically

Section

3MR

5MR

Metric Pitch (mm)

Material

Steel

Aluminium

Belt width (mm)

Vue en tableau

Grid view

Products only in stock

Reference		Stock France	Net price	Bore	Section	Metric Pitch (mm)	Material	Number of teeth	Belt width (mm)	De (mm)	Def (mm)	Mass (Kg)
3MRZ015-009 Tariff - Remanufacturing	Added	0	9,20 €	Pré alésée	3MR	3	Aluminium	15	9	13.6	18	N.C
3MRZ018-009 Tariff - Remanufacturing	Added	0	9,36 €	Pré alésée	3MR	3	Aluminium	18	9	16.4	20	N.C
3MRZ018-015 Tariff - Remanufacturing	Added	5 PCE	10,08 €	Pré alésée	3MR	3	Aluminium	18	15	16.4	20	N.C
3MRZ020-009 Tariff - Remanufacturing	Added	1 PCE	9,65 €	Pré alésée	3MR	3	Aluminium	20	9	18.3	23	N.C
3MRZ020-015 Tariff - Remanufacturing	Added	9 PCE	10,30 €	Pré alésée	3MR	3	Aluminium	20	15	18.3	23	N.C
3MRZ022-009 Tariff - Remanufacturing	Added	13 PCE	9,88 €	Pré alésée	3MR	3	Aluminium	22	9	20.3	25	N.C
3MRZ026-015 Tariff - Remanufacturing	Added	1 PCE	11,86 €	Pré alésée	3MR	3	Aluminium	26	15	24.1	28	N.C
3MRZ028-009 Tariff - Remanufacturing	Added	4 PCE	10,70 €	Pré alésée	3MR	3	Aluminium	28	9	26	32	N.C
3MRZ028-015 Tariff - Remanufacturing	Added	8 PCE	12,38 €	Pré alésée	3MR	3	Aluminium	28	15	26	32	N.C
3MRZ030-015 Tariff - Remanufacturing	Added	0	13,22 €	Pré alésée	3MR	3	Steel	30	15	27.9	32	N.C
3MRZ032-009 Tariff - Remanufacturing	Added	4 PCE	12,05 €	Pré alésée	3MR	3	Aluminium	32	9	29.8	36	N.C
3MRZ032-015 Tariff - Remanufacturing	Added	5 PCE	14,30 €	Pré alésée	3MR	3	Aluminium	32	15	29.8	36	N.C
3MRZ036-015 Tariff - Remanufacturing	Added	15 PCE	15,94 €	Pré alésée	3MR	3	Aluminium	36	15	33.6	38	N.C
3MRZ040-009 Tariff - Remanufacturing	Added	1 PCE	14,02 €	Pré alésée	3MR	3	Aluminium	40	9	37.4	42	N.C
3MRZ040-015 Tariff - Remanufacturing	Added	1 PCE	16,90 €	Pré alésée	3MR	3	Aluminium	40	15	37.4	42	N.C
3MRZ044-009 Tariff - Remanufacturing	Added	1 PCE	15,94 €	Pré alésée	3MR	3	Steel	44	9	41.3	48	N.C
3MRZ044-015 Tariff - Remanufacturing	Added	4 PCE	19,00 €	Pré alésée	3MR	3	Aluminium	44	15	41.3	48	N.C
3MRZ048-009 Tariff - Remanufacturing	Added	0	17,10 €	Pré alésée	3MR	3	Aluminium	48	9	45.1		N.C
3MRZ060-009 Tariff - Remanufacturing	Added	11 PCE	18,49 €	Pré alésée	3MR	3	Aluminium	60	9	56.5		N.C
3MRZ072-009 Tariff - Remanufacturing	Added	7 PCE	22,23 €	Pré alésée	3MR	3	Aluminium	72	9	68		N.C
5MRZ012-009 Tariff - Remanufacturing	Added	5 PCE	9,20 €	Pré alésée	5MR	5	Steel	12	9	18	23	N.C
5MRZ012-015 Tariff - Remanufacturing	Added	0	10,17 €	Pré alésée	5MR	5	Steel	12	15	18	23	N.C
5MRZ015-009 Tariff - Remanufacturing	Added	5 PCE	9,55 €	Pré alésée	5MR	5	Steel	15	9	22.7	28	N.C
5MRZ016-009 Tariff - Remanufacturing	Added	6 PCE	9,65 €	Pré alésée	5MR	5	Steel	16	9	24.3	28	N.C
5MRZ016-015 Tariff - Remanufacturing	Added	8 PCE	10,77 €	Pré alésée	5MR	5	Steel	16	15	24.3	28	N.C
5MRZ018-009 Tariff - Remanufacturing	Added	0	9,77 €	Pré alésée	5MR	5	Steel	18	9	27.5	32	N.C
5MRZ018-015 Tariff - Remanufacturing	Added	1 PCE	10,86 €	Pré alésée	5MR	5	Steel	18	15	27.5	32	N.C
5MRZ020-009 Tariff - Remanufacturing	Added	1 PCE	9,88 €	Pré alésée	5MR	5	Steel	20	9	30.7	36	N.C
5MRZ020-015 Tariff - Remanufacturing	Added	4 PCE	11,69 €	Pré alésée	5MR	5	Steel	20	15	30.7	36	N.C
5MRZ020-025 Tariff - Remanufacturing	Added	3 PCE	N.C	Pré alésée	5MR	5	Steel	20	25	30.7	36	N.C

0-30 sur 53
