Why choose an LW wide linear guide?
_cropped_300_200.webp)
Features
Ideal for single-rail applications. Thanks to the width of the rail, rigidity and load-bearing capacity are high against load moments in the direction of travel. This makes the LW Series ideal for compact, single-rail linear guidance systems.
High load capacity in vertical direction
The contact angle is fixed at 50 degrees, increasing load capacity and rigidity in the vertical direction.
High resistance to impact load
As with the NH and NS series, the staggered Gothic arch grooves withstand a high impact load over four rows.
High precision
Fixing the master rollers to the ball grooves is easy thanks to the Gothic arch groove. This makes it easy to measure ball grooves accurately.
Easy to handle and designed with safety in mind
The balls are retained in the holder and do not fall out when a ball track is removed from the rail. when a ball track is removed from the rail.
_cropped_250_280.webp)
How to identify your guide shoe?
Use the table below to identify the criteria for determining the desired guide shoe.
By following these tips, you should be able to choose the belts that are best suited to your application, and that operate safely and efficiently.
