Looking for a linear guide?
Our buying guide is here to help you choose a PE series miniature linear guide
The purpose of this guide is to show you the different types of linear guide available on the market.
It includes detailed technical information and advice to help you choose the guide best suited to your application and budget.
Looking for a linear guide?
Our buying guide is here to help you choose your product.
The purpose of this guide is to show you the different types of linear guide available on the market.
It includes detailed technical information and advice to help you choose the guide best suited to your application and budget.
Why choose a PE linear guide?
By following these tips, you'll be able to identify the linear guide best suited to your application, and operate safely and efficiently.
If you have any questions or comments on this definition, please use this form. Thank you in advance!
_cropped_300_200.webp)
Features
Ideal for single-rail applications. PE series linear guides are wide-rail miniature guides. Thanks to the wide rail, load capacity is high against load moments in the direction of travel.
Motion performance
The new recirculation component facilitates the circulation of steel balls.
Lightweight
The ball bearing slide is manufactured to be around 20% lighter than that of the LE series, thanks to the application of resin to part of its body.
Noise reduction
Resin components applied in the ball circulation circuits reduce collision noise between the steel balls and the inner wall of the circulation circuits.
Excellent dust protection
Designed to minimize the gap between the side of the rails and the inner walls of the slide, and prevent foreign bodies from entering the ball bearing slide. The structure is designed to prevent the generation of dust.
High resistance to corrosion
Highly corrosion-resistant martensitic stainless steel is incorporated as standard to provide excellent corrosion resistance.
Easy to handle
The safety design includes a retaining device that prevents the steel balls from coming out of the ball bearing slide, even when it is removed from the rail.
How to identify your guide shoe?
Use the table below to identify the criteria for determining the desired guide shoe.
By following these tips, you should be able to choose the belts that are best suited to your application, and that operate safely and efficiently.
If you have any questions or comments on this definition, please use this form. Thank you in advance!
